Dazzii Bar 510 Batteries

How To Use

1. Make sure that the bottom magnetic connector is properly connected to the bottom of the unit. The battery will not charge if the bottom connector is not attached.
2. Plug into a USB-C cable and connect to a power source, you will see the red light flash when the battery is connected.
3. Please fully charge the battery before first use, the light will turn green once charged, disconnect the device from the power source before use.
4. Remove the bottom magnetic connector and firmly screw in the 510-threaded cartridge of your choice.
5. Insert the cartridge into the device and ensure that the bottom magnetic connector is properly reconnected. The OLED Screen will appears a small battery icon to indicate that it is being charged when connected properly, or the screen won't change.
6. If the device is powered off, press the power button 5 times to turn it on.
7. Press the bottom button 3 times or auto inhale 3 times to change voltage.
8. Auto Inhale on the mouthpiece two times to activate pre-heat, or you can also press the bottom button two times to activate preheat. The preheat time will last 15 seconds @ 2.0V voltage, then will switch to your previously selected voltage.
9. Simply pull from the mouthpiece or push the button to activate the cartridge.

Specifications:

510 Cartridge Concealable 450mAh Pre-Heat OLED Screen Battery

Auto Draw Or Power Button For Convenience

Compact Pocket Size: Φ28 x 111mm

Weight: 40.5g

OLED Screen with Removable Magnetic Bottom

Cartridge Size: 14mm*68mm (Fits most 0.5ML ~ 2ML Carts)

Temperature Settings: 2.4V - 4.2V

Preheating Function: 1.8V Preheat for 15 seconds, On-screen countdown

Auto heat shut-off after 20 seconds of use for protection

Auto screen blanking after 5 seconds of no operation

30 minutes Safety Shutoff

See Your Battery Level , Voltage and Puff Counter All in 1 place

Cartridges Sold separately

Quick Start Instructions

The DAZZii BAR should be charged for an hour before the first use.

Remove the bottom magnetic end. Insert your 510 threaded cartridges.

Auto Draw Function: 5 x quick puffs to power the vape on, 2 x quick puffs to activate the pre-heat mode, and 3 x quick puffs to change the voltage settings.

Power Button Function:

Quickly press the power button 5 times to power ON/OFF the DAZZii BAR. Quickly press the power button 3 times to change the voltage to your favorite temp setting from 2.4V to 4.2V, 0.2V each. Quickly press the power button 2 times to activate pre-heat mode.

Pre-Heating:

Quickly pull from the mouthpiece twice to activate the preheat function, you can also press the bottom button 2 times to activate the preheat function.

The Preheating will last 15 seconds with 2.0V pre-heat voltage. In the preheating mode, On-screen countdown from 15s to 1s, press the power button 1 time or pull on the mouthpiece 1 time to stop preheating.

Normal Smoking Use:

Both auto inhale and button power are workable in normal vaping use mode, the guide bar and the sensor will illuminate. The sensor does not light in the preheating mode.

OLED Screen Display:

Power -ON Display: “DAZZLEAF”

Power -OFF Display: “OFF”

“LOW BAT”: The system detects that the power of the DAZZii BAR is too low to work and needs to charge.

“SHORT” : When the output is short-circuited, the MOS is automatically turned off to prevent burning.

“TIMEOUT”: Auto heat shut-off after 20 seconds of use for protection

OFF State: Hold down the Power button for 5 seconds to clear the number of puffs.

Battery and Charging:

Type-C Fast Charging

Attention: The DAZZii BAR battery should be charged for an hour before the first use.

Fully Charged: The battery symbol is displayed in full.

75%-100%: 4 Grids;

50%-75%: 3 Grids;

25%-50%: 2 Grids;

0%-25%: 1 Grids;

Battery dead: 0 Grids;
